Wel­come to JPK In­stru­ments AG

We are a lead­ing man­u­fac­tur­er of nano-an­a­lyt­i­cal in­stru­ments – par­tic­u­lar­ly based on atom­ic force mi­cro­scope (AFM) and op­ti­cal tweez­ers sys­tems – for life sci­ences and soft mat­ter ap­pli­ca­tions. Take a clos­er look at our so­lu­tions!


Atomic Force Microscopy Solutions

Specialized solutions for applications ranging from BioAFM and Polymer Research to Surface Science and NanoOptics

All NanoWizard® systems provide true integration of AFM with optical microscopy through the patented DirectOverlay™ feature for precise and easy work, and come along with a large variety of options and accessories.

Additionally, the NanoWizard® family comes with the  QI™ mode  – a force curve based imaging mode – as a standard.

Download accessories handbook

Nanowizard 1 NanoWizard® 4 NanoScience AFM

For applications in materials and polymer science reaching from single molecule experiments and electrochemistry to organic electronics

  Nanowizard 2 NanoWizard® 4 BioScience AFM

For applications in Life Science and Soft Matter research reaching from biophysics and cell biology to surface science and biomedicine

  Nanowizard 3 NanoWizard® ULTRA Speed AFM

Fast-Scanning and Super-Resolution AFM on inverted microscope enabling tracking of changes in samples in real time.

  Nanowizard 4 NanoWizard® NanoOptics AFM

Comprehensive solution for advanced experiments combining AFM and optical spectroscopy such as TERS, Aperture SNOM and sSNOM, confocal microscopy and nano manipulation in optical fields

  Nanowizard 5 BioMAT™ Workstation

For opaque samples combining upright optical microscopy with AFM for surface science and life science


Automated Force Spectoscopy

The New Standard in Force Spectroscopy

Force spectroscopy is a single molecule technique that allows the real-time study of molecular interactions on the nanoscale. Originating from the broad field of Atomic Force Microscopy, force spectroscopy provides the necessary sensitivity to characterize biomolecular interactions such as the unfolding forces of single proteins or forces of a single chemical bond.

For the very first time, the automation of force spectroscopy makes it fast enough to deliver high quality data in short time-frames. A large variety of accessories makes the system most flexible.

  ForceRobot 300 ForceRobot® 300

For single molecule applications. Automated force spectroscope with optional temperature control and fluidics system


Some Videos About Fast Scanning
Video 1 Living KPG7 fibroblast

The movie shows a living KPG7 fibroblast imaged in cell medium at 37 °C.

Video 2  Triangular DNA origami

Imaging of triangular DNA origami with 50 Hz line rate.

Video 3 Soft DNA Origami in buffer

Central pattern of a soft DNA Origami imaged in buffer

Video 4 PHB/V spherulite crystallization

This movie shows the growth front of a polyhydroxybutyrate-co-valerate (PHB/V) spherulite crystallization (24x).
